932F Wheel Loader

Low Shed 932F compact wheel loader is small in size, suitable for operation in narrow construction sites, warehouses and other spaces, with strong flexibility.
EngineYN27(42KW/56HP)
Rated Load1600kg
Dumping Height3000mm
Bucket capacity0.7m³

932F Wheel Loader
Low Shed 932F compact wheel loader is small in size, suitable for operation in narrow construction sites, warehouses and other spaces, with strong flexibility.

PARAMETERS

EngineYN27(42KW/56HP)
Rated load1600kg
Dumping height3000mm
Bucket capacity0.7m³
Tire20.5-16
Unloading distance760mm
Total weight3566kg
Size(L*W*H)5765*1900*2195mm
Bucket width1900mm
Arm thickness25mm
Boom center distance910mm
Cylinder size45/70mm
Cylinder size50/80mm
Thickness of upper plate20mm
Hinge plate25/20mm
Wheel track1480mm
Wheel base2315mm
Min.ground clearance 210mm

DETAILS

ADVANTAGES

Small and flexible: Low Shed 932F compact wheel loader is small in size, suitable for operation in narrow construction sites, warehouses and other spaces, with strong flexibility.

Lightweight and flexible: the wheel loader machine is light in weight, easy to carry and move, and can rotate 360 degrees at the same time, flexible and convenient to operate.

Efficient power: the loader is equipped with high-power and high-efficiency engines, which can quickly complete various tasks, and can be equipped with other brands of engines

High loading capacity: Despite being a compact wheel loader, the 932F compact wheel loader has a relatively high loading capacity and is capable of loading and handling a variety of materials.

Easy to operate: The compact wheel loader is easy to operate and easy to use. Save the time cost of training the driver.

Strong versatility: The compact wheel loader can be equipped with hundreds of attachments, such as buckets, forks, breakers, etc., and is widely used.

Easy maintenance: The compact wheel loader has the characteristics of simple structure and convenient maintenance, and the operation and maintenance costs are relatively low.

Environmental protection and energy saving: The compact wheel loader adopts an environmentally friendly and low-noise engine, which can meet environmental protection requirements, and also has the advantages of energy saving and emission reduction.
