LF932

PARAMETERS


Engine                               KW         YN27 42kW
Transmission case                    /            265

Tire                                 /             20.5-16
Rated load capacity                  kg             3000
Machine weight                       kg             4055
Size                                 mm          5245*1860*2650
Cylinder size                        mm             45/70
Cylinder size                        mm             40/70
Hinge plate                          mm             25/20
Wheel track                          mm             1510
Wheel base                           mm             1980
Clearance height of the gantry       mm             2250
Gate gantry inclination              °             6/12
Maximum lift height of the fork      mm             3060
Fork thickness*width*length          mm           45*120*1220
Load center distance                 mm             610
Min.ground clearance                 mm             240
