Tractor is an indispensable agricultural machinery, 'the main force', whether it is arable land, seeding, transportation, or supporting other agricultural equipment operations, tractors play a key role. Especially in Europe and South America and other agricultural regions, the use rate of tractors has been steadily high.

Relying on years of export experience and in-depth understanding of overseas users' needs, LUYU Machinery continues to develop and upgrade its tractor series. Through the feedback of actual working conditions and technical optimization, LUYU has made a lot of improvements in tractor performance, reliability, operating experience and other aspects. Today we will take you to understand how to judge the quality of the tractor? How to choose the right tractor for you?

Core advantages:

Forced-Lift Hydraulic System :

Function: Significantly enhances implement penetration into hard soil, boosting plowing efficiency.

Identification: Features two vertical hydraulic cylinders at the rear. Key advantage lies in bidirectional forced-lift capability.

Advantage: Bidirectional systems (identified by two hoses per valve) actively push implements down into hard soil. There are also lift-only systems (one hose per valve), relying solely on implement weight for penetration the soil.

Differences between Single/Dual function-Clutch:

Single-clutch system transmit engine power simultaneously to both wheels and PTO, causing unnecessary PTO wear and inefficient power management.

Dual-Clutch system provides separate control:

Wheel Drive: Controlled via standard clutch pedal (left foot).

PTO Engagement: Controlled via a dedicated lever (right side of the seat, similar to a parking brake).

Advantage: Reduces clutch wear, improves fuel efficiency, and allows independent operation of tractor movement and PTO-driven implements.

PTO (Power Take-Off) System :

Function: Transmits engine power to implements via a rotating shaft.

Compatibility: Features industry-standard 6-spline and 8-spline shafts.

Design: Utilizes a splined shaft that mates securely with implement couplings.

Advantage: Ensures broad compatibility with a wide range of agricultural implements and reliable power transfer.

Key Features Enhancing Performance & Durability:

Tire Options Optimized for Task:

Tubeless: Faster road speed, higher durability (steel-belted radial construction). Ideal for transport/light duty.

Tubed: Higher load capacity. Ideal for heavy fieldwork, albeit at lower road speeds.

Multi-Function Hydraulic Outputs:

Offers 1 to 4 independent hydraulic circuits (standard or optional based on model).

Function: Controls multiple hydraulic functions on implements (exempli gratia: lift, tilt, open/close) via remote couplers.

Advantage: Equivalent to a multi-spool valve, providing flexibility and efficiency for complex implements.

Precise Track Width Adjustment :

Stepped Adjustment: Achieves 4 distinct widths by reorienting the wheel hub's flange relative to the wheel rim (convex/concave sides, inner/outer mounting).

Continuous Adjustment: Utilizes sliding axle stubs and lockable bracket clamps (shaped) for infinite positioning within a range.

Advantage: Allows optimal spacing for different crops, implements, and terrain stability.

Braking Systems:

Drum Brakes: Offered in robust Air-Over-Hydraulic configuration (air compressor fills reservoir, hydraulic actuation) for reliable stopping power, suitable for larger tractors. Mechanical linkage drums available for smaller models.

Wet Disc Brakes: Features copper-asbestos friction linings within sealed, oil-bathed housings.

Advantage: Provides consistent braking performance, protects linings from contamination, and is designed for heavy-duty, off-road use.

Operational Convenience & User Focus:

Hydraulic Auxiliary Tank :

Function: External reservoir mounted behind the cab.

Advantage: Simplifies hydraulic fluid top-ups and increases system capacity for demanding hydraulic implements.

Quick-Hitch System :

Function: Enables fast attachment/detachment of implements.

Advantage: Saves significant time and labor compared to manual three-point hitch connection. Includes a Swinging Drawbar for smoother implement turning.

Superior Chassis & Powertrain:

Frame: Cross-braced reinforcement throughout (TE, TB, TC, TF, TS frames) for exceptional rigidity and strength in all directions.

Axles: Front axle by Guhe; Rear axle features a central differential lock. Combined with the reinforced frame, delivers outstanding off-road capability and durability.

Counterweight Systems :

Front Weights: Prevents front-end lift when using heavy rear implements.

Rear Wheel Weights: Split disc design (like half of a barbell plates) mounted directly onto the wheel hubs. Ensures traction and stability.

Premium Options & Comfort Options:

Advanced Sealing & Materials:

Oil Seals: Dual NBR/FKM (Nitrile/Fluorocarbon) seals provide exceptional resistance across a wide temperature range (-40°C to +200°C), ensuring long life in harsh conditions.

Operator Environment & Connectivity:

Hydraulic/Electric Auto-Lift Hitch: Automated implement control.

360° Camera System: Enhanced visibility and safety.

Tractor-Trailer Plug : Standard power outlet for lighting/electrical needs on towed equipment or trailers.

External Hydraulic Control Lever : Key Advantage: Allows single-operator implement hook-up from outside the tractor. Competitors often require one person outside and another inside the cab to operate controls.

Cab Comfort: Features sound insulation, tinted glass, and premium options including Grammer or high-quality Grammer-style suspension seats.
