1. Overall dimensions

5. Engine

1

Overall dimensions (mm)

6150*2350*3763

1

Model

Yuchai Power 4105T

2

Wheelbase (mm)

2290

2

Type

Turbocharger

3

Wheelbase (mm)

1950

3

Rated power (KW)

85

4

Minimum ground clearance (mm)

320

4

Rated speed (r/min)

2400

5

Minimum turning radius (mm)

6580

5

Cylinder number-inner diameter

4-105

2. Performance parameters

6. Transmission system

1

System pressure (Mpa)

28

1

Gearbox

Hydraulic shift

2

Machine weight (kg)

8200/8500

2

Number of gears

2 forward and 2 backward

3

Maximum speed (km/h)

28/38

3

Torque Converter

YJ280

4

Maximum climbing ability ( ° )

35

3. Digging parameters

7. Axle

1

Maximum telescopic digging depth (mm)

4000/5200

1

Type

First-stage wheel reduction bridge

2

Maximum digging radius (mm)

4800/6000

8. Tires

3

Maximum lifting height (mm)

5200/5950

1

Specification

14-17.5/19.5L-24

4

Bucket capacity (m3)

0.3

2

Service brake

Air-over-oil caliper brake

5

Excavator rotation angle ( ° )

190

3

Parking brake

Air brake

9. Oil volume

4. Loading parameters

1

Fuel tank (L)

100

1

Maximum dumping height (mm)

2742

1

Hydraulic oil tank (L)

100

2

Maximum dumping distance (mm)

1062

10. Others

3

Bucket capacity (m3)

1

1

Drive type

Four-wheel drive

1

Speed type

Hydraulic shift

2

Control system

Electromagnetic hydraulic pilot control

The specific parameter changes are subject to the actual product.
